Acoustic Isolation Products for Walls
It is important that the walls of a space sensitive to noise or vibration transmission are isolated from the main building structure. These acoustically isolated walls can be built on a floating floor or specially designed wall support plates. If the wall requires lateral support, anti-vibration wall braces will be required.
Mason UK have a range of products available which can isolate most wall types, including stud and masonry. A large range in wall weights can be accomodated and we can also design or supply products to suit most anti-vibration requirements. Scroll down to view our wall noise control products.
If you would like to order or learn more about these products, please contact Mason UK’s acoustic engineers.
Cross section of an isolated block wall
Cross section of an isolated partition wall
Cross section of an isolated partition wall on NPS
Related Products
DNSB-A Sway Brace/Wall Tie
DNSB-A is a low frequency wall tie. This sway brace has a bolt end for stud walls or hooked end for masonry walls.
DNSB-BM Wall Tie/Sway Brace
This DNSB-BM is our most popular acoustic sway brace. It is a low frequency wall tie. You have a choice of a bolt end for stud walls or hooked end for masonry walls.
WIC Sway Brace/Wall Tie
The WIC acoustic wall tie is a low profile, low cost sway brace. Minimum cavity = 40mm
WIC-2-SM Sway Brace/Wall Tie
Type WIC-2-SM is a masonry wall tie designed to connect two masonry walls built together. There is no limit on wall thickness or cavity for this sway brace
WIC-2-90 Sway Brace/Wall Tie
The Type WIC-2-90 acoustic sway brace/wall tie is a 90-degree variant of our popular WIC product. It is designed to tie internal and external walls together. One side is designed to be imbedded into blockwork mortar joints, the other to be fixed into the opposing wall with suitable fixings.
DSSB – Double Spring Sway Brace/Slam Wall Isolator
The DSSB Double Spring Sway Brace/ Slam Wall Isolator is a specially designed product, which was first thought up to solve a problem, but become a popular solution for such constructions as slam/rebound walls. As a result of this popularity, we decided to add it to our vast product range.
AB-716 Angle Head Restraint
The AB-716 is an angled, head restraint for the top / and of block and stud walls.
NPS – Partition Support
NPS Partition Support isolates the bottom channel of steel stud walls. NPS is held in place by a frame or hammer fixing.
SWW Masonry Isolation
Mason’s SWW type acoustic wall isolation strips are designed to isolate a wall from the base slab. The SWW is designed to suit width and wall load.
AFA – Acoustical Furring Attachment
This AFA is a acoustical furring attachment for use with metal or wood stud walling. It uses a low dynamic stiffness natural rubber for effective isolation and the metal elements of the AFA are completely encapsulated.
